Type: Brushless outrunner
Size: 25
Recommended Prop Range 3S: 14 x 8 folding; 4S: 12 x 8 folding
Park 250 Brushless Outrunner Motor 2200Kv
Key Features
Ideal for 3D models 4–6 oz (115–170 g) and sport and scale models 6–12 oz (170–340 g)
Up to 55 watts
Designed for firewall mount or carbon tube mount
Integrated prop saver design
Extremely quiet and lightweight—just .5 ounces (14 grams)
Upgraded performance motor for indoor IPS and 180 motors
High-torque, direct-drive alternative to inrunners
Includes mount, mounting hardware and 2mm gold BL connectors
High-quality construction with ball bearings and hardened steel shaft
Great lightweight outrunner for small indoor foamies
Needed To Complete
6–10A brushless ESC
2S Li-Po or 5- to 7-cell Ni-Cd/Ni-MH
5.5 x 4.5–8 x 6 Slow Flyer prop
Specs
Speed Control: 6A–10A brushless
Bearings or Bushings: Two 2 x 5 x 2.5mm Bearings
Cells: 6 Ni-MH/Ni-Cd or 2 Li-Po
Idle Current (Io): .45A
Motor Design: Outrunner
Overall Diameter: 22mm (.85 in)
RPM/Volt (Kv): 2200
Recommended Prop Range: 5.5 x 4.5–8 x 6 Slow Flyer
Resistance (Ri): .25 ohms
Size: Upgrade for 180-size
Voltage: 6.0–8.4V
Park 480 Brushless Outrunner Motor, 1020Kv
Key Features:
Perfect match for 3D park flyers weighing 20–30 oz (565–850 g)
Ideal for scale park flyers 25–35 oz (710–990 g)
Ideal for models requiring up to 275 watts of power
High-torque, direct-drive alternative to inrunner brushless motors
Includes mount, prop adapters, and mounting hardware
External rotor design—4mm shaft can easily be reversed for alternative motor installations
Slotted 14-pole outrunner design
High-quality construction with ball bearings and hardened steel shaft
Quiet, lightweight operation
Needed To Complete:
25A–40A brushless ESC
2S–3S Li-Po or 6- to 10-cell Ni-MH/Ni-Cd
10x7–12x6 propeller
Specs:
Speed Control: 25A to 40A brushless
Bearings or Bushings: One 4 x 9 x 4mm Bearing and One 4 x 10 x 4mm Bearing
Cells: 6-10 Ni-Cd/Ni-MH or 2-3S Li-Po
Idle Current (Io): 1.10A @ 8V
Motor Design: Outrunner
RPM/Volt (Kv): 1020
Resistance (Ri): .06 ohms
Shaft Diameter: 4mm (.16 in)
Size: Park flyer
Voltage: 7.2–12
Wire Gauge: 16 AWG
Power 10 Brushless Outrunner Motor, 1100Kv
Key Features:
Equivalent to a 10-size glow engine for 32–48 ounce (910–1360 g) airplanes
Ideal for 3D airplanes weighing 28–36 ounces (790–1020 g)
Ideal for models requiring up to 450 watts of power
High-torque, direct-drive alternative to inrunner brushless motors
Includes mount, prop adapters and mounting hardware
External rotor design—5mm shaft can easily be reversed for alternative motor installations
Slotted 14-pole outrunner design
High-quality construction with ball bearings and hardened steel shaft
Quiet, lightweight operation
Needed To Complete:
40A ESC
6- to 10-cell Ni-MH/Ni-Cd or 2–3S Li-Po
10x5 to 12x6 electric props
Specs:
Bearings or Bushings: One 5 x 14 x 5mm Bearing and One 5 x 11 x 5mm Bearing
Cells: 6–10 Ni-MH/Ni-Cd or 2–3S Li-Po
Idle Current (Io): 2.10A @10V
Motor Design: Outrunner
RPM/Volt (Kv): 1100
Recommended Prop Range: 10x5–12x6
Resistance (Ri): .043 ohms
Shaft Diameter: 5mm (.20 in)
Size: 10-size
Voltage: 7.2–12
Wire Gauge: 16 AWG
Power 15 Brushless Outrunner Motor, 950Kv
Key Features
Equivalent to a 15-size glow engine for sport and scale airplanes weighing 36–56 oz (1020–1590 g)
Ideal for 3D airplanes weighing 32–40 oz (910–1135 g)
Ideal for models requiring up to 575 watts of power
High-torque, direct-drive alternative to inrunner brushless motors
Includes mount, prop adapters and mounting hardware
External rotor design—5mm shaft can easily be reversed for alternative motor installations
Slotted 14-pole outrunner design
High-quality construction with ball bearings and hardened steel shaft
Quiet, lightweight operation
Speed Control: 40-45A brushless
Bearings or Bushings: One 5 x 14 x 5mm Bearing and One 5 x 11 x 5mm Bearings
Cells: 8-12 Ni-MH/Ni-Cd or 3-4S Li-Po
Idle Current (Io): 2.00A @10V
Motor Design: Outrunner
RPM/Volt (Kv): 950
Recommended Prop Range: 10x6 - 13x6.5
Shaft Diameter: 5mm (.20 in)
Size: 15-size
Voltage: 7.4–14.4V
Wire Gauge: 16 AWG
Key Features
Ideal for airplanes requiring up to 850 watts of input power
Equivalent to a 25-size glow engine for high-power airplanes weighing 3- to 5.5-pounds (1.4- to 2.5-kilograms) or 15-sized high-speed electric Formula One racers weighing up to 4 pounds (1.8 kilograms)
Includes mount, prop adapter and mounting hardware
External rotor design; the shaft can easily be reversed for alternative motor installations
High-torque, direct-drive alternative to inrunner brushless motors
Quiet, lightweight operation
High-quality construction with ball bearings and hardened 5mm steel shaft
Overview
Pilots demanding more speed and power from their motors should look at E-flite's Power 25 BL Outrunner Motor, 1250Kv. Delivering more power than the 870Kv Power 25 (and at higher RPM's), it was designed specifically for the NMPRA's EF1 electric pylon racing class.
The 1250Kv Power 25 BL motor was created for for high-power airplanes weighing 3- to 5.5-pounds (1.4- to 2.5-kilograms) or 15-sized high-speed electric Formula One racers weighing up to 4 pounds (1.8 kilograms
Specs
Speed Control: 60A Pro Brushless
Bearings or Bushings: One 5 x 14 x 5mm Bearing and Two 5 x 11 x 4mm Bearings
Cells: 3S - 4S Li-Po 10 - 14 Ni-MH/Ni-Cd
Idle Current (Io): 2.00A
Motor Design: Outrunner
RPM/Volt (Kv): 1250
Recommended Prop Range: 8x6E to 8x8E (4S) or 8x8E to 10x10E (3S)
Resistance (Ri): .02 ohm
Shaft Diameter: 5mm (.20 in)
Size: 25
Voltage: 11.1–16.8V
Wire Gauge: 14 AWG
Power 32 Brushless Outrunner Motor, 770Kv
Key Features
Equivalent to a 30- to 36-size glow engine for sport and scale airplanes weighing 3.5–6 lb (1.6–2.7 kg)
Ideal for 25- to 36-size 3D airplanes up to 4.5 lb (2 kg)
Ideal for models requiring up to 800 watts of power
High-torque, direct-drive alternative to inrunner brushless motors
Includes mount, prop adapter and mounting hardware
Quite, lightweight operation
External radial rotor design—5mm shaft can easily be reversed for alternative motor installations
High-quality construction with ball bearings and hardened steel shaft
Slotted 14-pole outrunner design
Needed To Complete
- 60A brushless ESC
- 3–5S Li-Po or 10- to 16-cell Ni-MH/Ni-Cd
- 11x7 to 14x10 prop; 10x10E tested on 5S in Sundowner 36
Overview
The Power 32 is designed to deliver clean and quiet power for 30- to 36-size sport and scale airplanes weighing 3.5 to 6 pounds (1.6 to 2.7 kilograms), 25- to 36-size 3D airplanes up to 4.5 pounds (2 kilograms), or models requiring
up to 800 watts of power. It's an especially good match for the Gee Bee Tiger Moth, TopFlite DC-3, Phoenix Sonic 25 and 3D airplanes such as the E3D.
Specs
Bearings or Bushings: One 5 x 14 x 5mm Bearing and One 5 x 11 x 5mm Bearing
Cells: 10–16 Ni-MH/Ni-Cd or 3–5S Li-Po
Idle Current (Io): 2.40A @ 10V
Motor Design: Outrunner
Overall Diameter: 42mm (1.70 in)
RPM/Volt (Kv): 770
Recommended Prop Range: 11x7 to 14x10
Shaft Diameter: 5mm (.20 in)
Size: Replacement for a 30- to 36-size glow engine
Voltage: 12–16.8V
Wire Gauge: 14 AWG
Power 46 Brushless Outrunner Motor, 670Kv
The Power 46 is designed to deliver clean and quiet power for .40 to 46-size sport and scale airplanes weighing 4 to 7 pounds (1.8–3.2 kg), 25- to 40-size 3D airplanes up to 5 pounds (2.2 kg), or models requiring up to 925 watts of power.
Key Features:
Equivalent to 40- to 46-size glow engine for planes weighing 4–7 lb (1.8–3.2 kg)
Ideal for 25- to 40-size 3D airplanes up to 5 lb (2.2 kg)
Ideal for models requiring up to 925 watts of power
High-torque, direct-drive alternative to inrunner brushless motors
Includes mount, prop adapters and mounting hardware
External rotor design—6mm shaft can easily be reversed for alternative motor installations
Slotted 14-pole outrunner design
High-quality construction with ball bearings and hardened steel shaft
Quiet, lightweight operation
Needed To Complete;
60A brushless ESC
4S–5S Li-Po or 12- to 16-cell Ni-MH/Ni-Cd
12x8 to 14x10 prop
